Characteristics
• High frequency on-line double conversion technology
• Advanced dual-core DSP control technology and 3-level technology
• Active power factor correction (APFC), input power factor up to 0.99
• System efficiency is improved to 96%, energy saving rate is doubled
• Output power factor 1.0
• Dual input design, supporting independent bypass
• Advanced digital and parallel technology, providing higher reliability than single system
• Wide input voltage range
• 50 / 60 Hz auto-sensing frequency
• 50 / 60 Hz frequency conversion mode
• Work efficiency up to 98% in ECO mode
• Fan speed varies intelligently with load, reducing noise and extending its service life
• Conformal coating technology to make UPS operate in harsh environment for a long time
• Flexible battery configuration setting, selectable battery numbers: 32~ 40 pcs
• Digitally controlled charger (Max.10 A)
• Ability to switch on the UPS by battery in the absence of mains power (Cold start)
• Zero switching time for UPS power supply mode when the mains power is unstable, ensuring the output is uninterrupted
• Compact internal layout, small footprint
• 5 inches LCD colorful touch screen, friendly human & machine interface
• Powerful background software for parameters configuration and online upgrade
• Advanced multi-platform communication for UPS monitoring: RS232, USB, RS485, dry contacts, SNMP card, Wi-Fi card and GPRS card
• Linear derating in low voltage input, reducing battery discharging times, extending the service life of battery
• Intelligent battery management, automatic equalized and float charging control, charger dormancy control, improving the reliability of charger and extending the battery life
• Effective hardware and software protection, robust self-diagnosis function, abundant event log for future check
• Standard RS232, USB, RS485, EPO, Dry contacts, Parallel port
• Optional SNMP card, WI-FI card, GPRS card, SMS alarms
